[Nova II 1x1] Fixture Details & Buttons

1. Quick Clip Key Hole

2. Quick Clip Key Hole

3. Quick Release Lever

4. Tilt Lock Handle

5. NOVA 1x1 Removable Yoke with Junior Pin

6. TVMP Pin (1.125in/28mm)

7. Top Handle

8. Anti-Rotating 3/8in Mounting Point

9. Quick Release Lever

10. LAN Port 1 / 2

11. AC In/Out(100-240VAC)

12. 5-Pin XLR DMX In / Out

13. Sidus NFC

14. Anti-Rotating 3/8in Mounting Point

15. Tilt Lock Handle

1. Power Button

2. LCD Display

3. Select Wheel

4. Menu Button

5. Light Mode Button

6. Preset Button

7. Back Button

8. Quick Clip Lever

9. Quick Clip Key Hole (For stacking)

10. Quick Clip Key Hole (For stacking)

11. Quick Clip Lever

12. Quick Clip Lever

13. Quick Clip Locking Key

14. Quick Clip Locking Key

15. Quick Clip Lever

1. Control Panel Indicator Light

Identify the parts, ports, and controls on the NOVA II 1x1 lamp head.
